| DN4 | OD9.53 | 95 mm-10,5 mm | 1/8" | 0,003～0,142 m³/u
0,047～2,374 l/min
0,013～0,627 gal/min |
| DN8 | OD12.7 | 12,4 mm-13,1 mm | 1/4" | 0,011～0,570 m³/u
0,190～9,496 l/min
0,050～2,509 gal/min |
| DN10 | OD15 | 14,5 mm-15,4 mm | 3/8" | 0,026～1,282 m³/u
0,427～21,366 l/min
0,113～5,644 gal/min |
| DN15 | OD20 | 16,5 mm-23,0 mm | 1/2" | 0,046～2,279 m³/u
0,760～37,984 l/min
0,201～10,034 gal/min |
| DN20 | OD25 | 25,0 mm-30,0 mm | 3/4" | 0,103～5,128 m³/u
1,709～85,464 l/min
0,452～22,577 gal/min |
| DN25 | OD32 | 32,0 mm-35,0 mm | 1" | 0,182～9,116 m³/u
3,039～151,935 l/min
0,803～40,137 gal/min |
| DN32 | OD40 | 38,0 mm-45,0 mm | 1-1/4" | 0,285～14,244 m³/u
4,748～237,399 l/min
1,254～62,714 gal/min |
| DN40 | OD50 | 48,0 mm-54,0 mm | 1-1/2" | 0,410～20,511 m³/u
6,837～341,854 l/min
1,806～90,309 gal/min |
| DN50 | OD63 | 58,0 mm-64,0 mm | 2" | 0,729～36,464 m³/u
12,155～607,741 l/min
3,211～160,549 gal/min |
| DN65 | OD75 | 72,0 mm-78,0 mm | 2-1/2" | 1,140～56,976 m³/u
18,992～949,595 l/min
5,017～250,857 gal/min |
| DN80 | OD90 | 80,0 mm-92,0 mm | 3" | 1,641～82,045 m³/u
27,348～1367,417 l/min
7,225～361,234 gal/min |
| DN100 | OD110 | 108,0 mm-116,0 mm | 4" | 2,917～145,858 m³/u
48,619～2430,963 l/min
12,844～642,194 gal/min |
| DN125 | OD140 | 132,0 mm-142,0 mm | 5" | 4,558～227,903 m³/u
75,968～3798,380 l/min
20,069～1003,429 gal/min |
| DN200 | OD220 | 218,0 mm-228,0 mm | 8" | 11,669～583,431 m³/u
194,477～9723,852 l/min
51,376～2568,778 gal/min |
